ASME Pressure Vessel 50Ton 100cbm 100000L LPG Storage Tank lpg Bullet Gas Storage Tank
Product Description
1. LPG Tank Storage Content: LPG Gas, Propane, Butane, Liquid Ammonia, etc.
2. Tank Design Standard: GB150-2013, ASME Standard with U STAMP.
3. Test: 100% Radiaographic Test, Magnetic Power Test, Water Pressure.
Product Specification
Product Description
1. LPG Tank Storage Content: LPG Gas, Propane, Butane, Liquid Ammonia, etc.
2. Tank Design Standard: GB150-2013, ASME Standard with U STAMP.
3. Test: 100% Radiaographic Test, Magnetic Power Test, Water Pressure.
Product Specification
| Item | Unit | Specification | |||||||
| Loading object | CLW25-12-12 | ||||||||
| Material | Propane Gas | ||||||||
| Designed loading Parameter | Option | Q345R, 16MnIII, Q370R | |||||||
| Kg/m3 | 420~ 500 | ||||||||
| Dimension | mm | 7594*2124*2714 | |||||||
| Net Weight | Kg | 24960 | |||||||
| Designed Pressure | Mpa | 1.77 | |||||||
| Max Working Pressure | Mpa | <=1.6 | |||||||
| Designed Temperature | C | -20~50 | |||||||
| Volume | m3 | 25 | |||||||
| Body thick | mm | 12 | |||||||
| Cover thick | mm | 12 | |||||||
| Man Hole | mm | 450 | |||||||
| Top Safety Valve Port | mm | 80 | |||||||
| Life Year | Year | 10 | |||||||
| Input and output | |||||||||
| Liquid input Port | mm | DN50 ( 2 Inch) | 2.5Mpa | ||||||
| Liquid Output Port | mm | DN50 (2 Inch) | 2.5Mpa | ||||||
| Bottom Air gas input Port | mm | DN50 (2 Inch) | 2.5Mpa | ||||||
| Waste Liquid Output Port | mm | DN50 (3 Inch) | 2.5Mpa | ||||||
| Top Gas Let Out Port | mm | DN50 (3 Inch) | 2.5Mpa | ||||||
| Liquid Level Indicator Port | mm | DN20 | 2.5Mpa | ||||||
| Essential Device for option | |||||||||
| Safety Valve, Temperature Gague, Pressure Gauge | |||||||||
| Option~ flange | |||||||||
| Production Standard | |||||||||
| China GB 150 Pressure Vessel Manufacturer Standard, Or ASME Standard | |||||||||
| Designed Valid Year, at least 10 year | |||||||||
Product Show
We supply customized drawing for every storage tank
| Nozzle data | |||||
| Characters | Size | Pressure(MPa) | Connect | Junction surface | Purpose |
| a | DN50 | 25 | HG20592-WN | RF | Drain outlet |
| b | DN50 | 25 | HG20592-WN | RF | Liquid phase outlet |
| c1-2 | DN50 | 25 | HG20592-WN | RF | Gaseous phase balanced outlet |
| d | DN50 | 25 | HG20592-WN | RF | Liquid inlet |
| e | M33*2 | Screw-thread | Thermometer connection | ||
| f1-2 | DN25 | 25 | HG20592-WN | RF | Lever gauge connection |
| g | M20*1.5 | Screw-thread | Pressure Gage | ||
| h | DN100 | 25 | HG20592-WN | RF | Safety valve connection |
| i | DN50 | 25 | HG20592-WN | RF | Emptying mouth |
| j | DN450 | 25 | HG20592-WN | FM | Manhole |
Main Structure Diagram
We supply package solution for lpg station building as follows
